World War II Project - Horsa Glider - Part III

The wings are the last piece to assemble in the instructions. If you build as directed you are just about done because you would have been adding the skin as the last part of each sub assembly, something I decided to wait on. Be aware there are some fragility here until you skin them. The wings are constructed from two pieces  (each) of MDF so they are quite heavy. I'm looking at the wing spars that hold this assembly together and I have my doubts, hopefully the cardboard skin will hold everything together, and it should.

There is a piece mislabeled here as well. The long spar that joins the two wing halves together is noted as #1 on the diagram and as L in the instructions. The assembly is pretty straight forward, just be sure that all the slots line up between the upper and lower surfaces of the wings so that the spars will fit correctly.  Test fit, test fit test fit!

After the wings I went to work on the undercarriage. This is another point where are there are some very small pieces and it won't take much to break them. A little judicious filing will make things much easier. This is another spot in the instructions where a part is labeled incorrectly. The diagram shows the Front Frame as part #1 and the instructions refer to it as Q. Its not a big issue since there is nothing even remotely similar to it.  The one issue I ran into is that the two wheels are each constructed of four parts. On the frame those parts are on there are only three pieces for each wheel. I don't know what I did with the two part "V"s that make up the outside portion of the wheel. I was throwing away frames as I finished them and I thought I was making sure that I snagged any misc pieces from those but as it sits they are definitely missing. Odds are no one is going to notice anyway so I'm not going to go crazy over it.

Now that I have everything together I'm ready to move on to applying the "skin"

Here are all the pieces for the wing except the long spar (L)

Here is the upper wing with the ribs in place and the lower wing ready to be glued together. be sure that your engraved sides of the wing are facing away from each other! This is a big surface so clamping the two wing halves together is required (in my opinion, long time readers should know how I feel about clamping at this point).

The lower wing, engraved side

The upper wing, engraved side, ribs attached.

Everything glued together, I got a little sloppy with the glue here, but it will be covered by the cardboard "skin"

Wings assembled

Spars added. The wing is ready for the "skin" now.

The under carriage. Note that I only have three pieces for each wheel, not sure what happened to the fourth piece. The two triangles are the support struts for the tailplane.

The under carriage assembled. Note that the spot where the front frame and the undercarriage frame come together at the wheel is a weak point because the MDF is thin. I broke this joint on one side trying to force the wheels on to the tab. Sanding the tab slightly will make it easier to fit the wheels on and help keep you from breaking the joint there.


Two unknown pieces that were on one of the frames that I held on to. I have no idea where these goes or what their purpose is. I have gone over the instructions and I don't believe I missed anything in the assembly process.

Sunday, June 18, 2017

World War II Project - Horsa Glider - Part II

I fired up the airbrush and did a quick application of paint to what will be the inside of the glider skin. I also painted the cockpit and the interior floor, door ramp and bulkheads with the same color. Most of the pictures I saw actually had a two tone scheme on the inside but I just didn't want to go that far with this one. I'm actually questioning why I even bought this one, it may never even end up on the table. It certainly doesn't appear in any of the Kampfgruppe Von Lucke scenarios from the Two Fat Lardies Pint Sized Campaign. Still its been kind of a fun build up to this point.


Here I painted the "inside" of the cardboard used for the glider skin using AMMO US APC Interior Green thinned down with a bit of white. I'll have to watch for overspray around all those open windows though. Masking is going to be a bit tricky, or I may just have to brush paint the fuselage.


Here are the finished glider components with their coating of interior green. There are a lot of variations on the interior color so, much like camouflage colors, its hard to be wrong.


I decided that I would leave off the skin and do that at the very end just so I could be more methodical with it. I don't see anything in the assembly sequence that would cause a problem by doing that and right now it just makes everything easier to handle.


After the airbrush work I started in on the next sequence; the tail. I had some issues with this assembly. First off on my kit the fit on all the parts was incredibly tight, to tight to make it easy to assemble. To make it easier I would highly recommend filing the slots a bit before trying to assemble the ribs to the tail core (S) and tail assembly (U). You will be much happier at the end.


While I followed the assembly sequence as written I would recommend that you don't. The tail core piece (S) is easier to get properly placed by using the ribs (V, W & X) than by using the end bulkhead (U) as stated in the sequence.

Watch for the point where the rudder attaches to the rest of the tail piece (T). I didn't even realize that I had snapped it off while I struggled getting the end bulkhead (U) into place (the fit is much to tight). Also the end bulkhead (U) actually has a top! On the tail piece (T) the upper tab and lower tab that the bulkhead attaches to are different sizes and correspond to different sized slots on the bulkhead. I had it upside down the first time and snapped it in half trying to take it off, which is about the same time the rudder snapped off.

Also attach the tailplane brackets (Z) to the tailplane before you attach it to the rudder. The fit is incredibly tight and at first I thoughyt they might not actually be the right size to fit into the slot on the tailplane. If you haven't broken off the rudder yet, you could well do it trying to get these in place.

I won't try and attach the rudder back into position until after I have put on the cardboard skin. I suspect the skin will be easier to put with it out of the way and I won't risk breaking it a second time. In the end it might need to be pinned in place.

Here is the action sequence:
Here are the components for the tail assembly

By trying to follow the sequence I broke off the rudder and snapped the end bulkhead in half. A little judicious filing of the tabs and slots would have kept this from happening

Plan B, attach the ribs first which gets the tail core into the proper position

You can see the tabs on the tail core sticking through the final rib assembly (the ribs are all two pieces). Those tabs are different sizes.

Since I had conveniently snapped the bulkhead in half, I lined them up so you can see that, indeed, the slos are actually different sizes and not by very much. There is no indication of direction in the instructions.

Now I have everything in place.

This should be a single assembly at this point but for me it has become two. All the parts for the tail have incrediably tight fits including the wing support brackets on the tailplane. I would attach those brackets before attaching the tailplane tot the rudder, especially if you haven't already broken the rudder off.

Saturday, June 17, 2017

World War II Project - Horsa Glider from Sarissa Precision - Part I

I received this kit as part of the pre-order bundle for the new plastic box set of plastic British Paras. I had already seen some comments on LAF about if it would be better to scratch build one or build the kit or how accurate it really is. My concern is how it goes together and how it looks alongside the miniatures. I'm less concerned, oddly enough for me, with the historical accuracy. Unless I'm going to be fighting Pegasus Bridge a lot this is going to be a fairly rare addition to the terrain on the battlefield so I just want it to look good and be identifiable by the participants and anyone that happens to walk by.

As old hands will know I'm a bit of a stickler for instructions. While I can usually figure things out there is no need to make it more difficult than it needs to be and good instructions go along way in helping us get things to the table. As I read through the first bit which involves assembling the front portion of the superstructure there are a couple of spots where parts are mis-identify, not a huge deal if you are paying attention but it can be initially quite confusing for the written direction to indicate one letter or number and the diagram with the description shows different letters and/or numbers. In this case the upper spine is labeled M in the diagram and in the written portion is listed as part K but in the section prior part K has already been noted as being the floor. Also the two end bulkheads are noted as being part 3 in the instructions but are shown as B on the diagram. The wheel housings are also identified as part M in both the instructions and the diagram but M is already identified as the upper spine. You just have to pay attention, but it would be nice if a little editing had been applied to the instruction pages before they were printed up.

Something very important to watch for is the configuration of Frame 1 when glued to Frame 2. There are two of these assemblies and you must make sure that the Frame 2 portions are facing each other when you glue them to Frame 1. This forms the door and it won't work very well if you manage to get them on the wrong sides! When you glue Frame 1 to Frame 2 make sure that they are lined up properly as well or there will be trouble when you glue them to the floor (K).

At this point, except for the door ramp I have avoided using any of the cardboard wraparounds that will form the skin of the glider. I want to paint the interior first. I have seen several variations so I'm just going to go with a very light interior green. Although there is a version with the upper 2/3rs being the interior green and the bottom 1/3 (or so) being a dark green. This will just be a quick job with the airbrush just so you can see something when everything is opened up.

Oh and if you are going to label the parts on the diagram and talk about those labels in the instructions you could at least repeat those letters and numbers right on the sprues!

Here we go with a few pictures (okay, a lot of pictures):
This is the sprue that contains the primary fuselage parts The only two I haven't used at this point, which keeps me from throwing it away are the two rocker shaped pieces at the bottom center. Starting at the top is the upper spine (M). On the next row from left to right End Bulkhead (B or 3), Frame 2, there are two pieces here the other portion is the door side (N) , then Frame 1, and another Frame 1. On the third row is Frame 1, center bar (O), Frame 2/Door Side (N), another Frame 1 and then the final End Bulkhead (B or 3).
Next row is Floor K. Under that is the bottom spine (L). Under that are the 2 Wheel Housings (M) after that are the two unidentified (as of yet) rocker pieces.

The parts I started with. I cheated here and I'm already gluing the Frame 1 to Frame 2 under those little metal weights. Note that there are still two Frame 1s that will fit into the back two slots on the floor. The ones I'm gluing together here will go into the front two slots

And here we have the pair of Frame 1 and Frame 2 combinations glued in place to the floor. Important to note here that the Frame 2 pieces have to face each other when you glue them to the Frame 1s. Your door won't work otherwise! Its also a rather tight fit on the door side of the floor to get the frames in place. Be careful and don't break anything and don't remove those two nubs that appear to be in the way. Removing the nubs will mean you will be gluing your door into place rather than having a nice operating version.
And from the bottom.

All the frames glued to the floor.

Adding the top spine (allegedly part M). This is thin MDF and is easily broken. Be gentle when pushing tabs and slots together you don't need anything snapping at this stage. In particular the fit up front at the door frames can be very tight especially if you didn't make sure everything was nice and square when you glued those frames together.

And here with the bottom spine in place as well as the two end bulkheads. Its important to make sure everything is pretty square (or circular as the case may be) at this point. Oh and the fragility of the MDF is important here too, don't get in a rush and force things together.

A view from the bottom

Order is important here as you assembly the door. The two side pieces (N) must be in place (not glued, or it won't pivot) before the center bar (O) is glued between them. I found it easier to glue the center bar to one side and then get everything into the correct position.

Watch for excess glue or you might be permanently gluing your door shut!

Add the cardboard piece for the ramp, again watch for excess glue.

And everything swung into place.

The parts to form the cockpit

All these pieces fit together very tightly, I probably didn't even need glue. Note that one half of the back wall is already in place.


Sliding in and gluing the other half of the cockpit back wall

Adding the side braces of the cockpit. This fit is not quite so tight so I made sure to apply glue where the side frame meets the back bulkhead on the top and the bottom.

The back bulkhead being glued into place. The outer skin will attach to this portion of the bulkhead.

The second half of the back bulkhead glued in place. This piece will be exposed as it forms the plug that allows you to attach it to the fuselage.
